Hall closed loop current sensor HAS4009 Rated input ±20A/±50A/±100A Rated output 2.5V±0.625V - PowerUC

Closed loop current sensor HAS4009 Rated input ±20A/±50A/±100A Rated output 2.5V±0.625V

PowerUC

Shipping calculated at checkout.
Only 2 left!

Model：HAS4009

Closed loop,basbar built-in, PCB mounting type; Detect DC,AC and pulse current.

Technical index:

Flame resistance：UL94-V0

Operating temperature：-25～+70℃

Storage temperature：-25～+70℃

Bandwidth：DC～150kHz

Dielectric strength：3.5KV 50Hz 1min

Electric parameters:

DOWNLOAD
