Through core type precision current transformer TA22S Rated input 0-80A(160A)；0-100A(200A)；0-150A(300A) Rated output 0-80mA(160mA)；0-50mA(100mA) - PowerUC

Through core type precision current transformer TA22S Rated input 160A 200A 300A Rated output 160mA 100mA

PowerUC

Shipping calculated at checkout.
Only 15 left!

Model:TA22S

Characteristics:

Can through 15×3 copper bar, crimp terminals output. Silicon steel sheet core. Non-linearity superior to 5‰. High overloading ability.

Technical index:

Mounting type：Plate mounting

Material of the core：Silicon steel sheet

Flame resistance：UL94-V0

Execution standard：GB20840-2014

Operating temperature：-20℃～+70℃

Storage temperature：-30℃～+80℃

Frequency range：50Hz-60Hz

Dielectric strength：≥3.5KV 50Hz 1min

Electrical parameters:



DOWNLOAD
