Three-phase current transformer  3TA030BL Rated input 0-150A;0-200A; 0-250A ; 0-300A Rated output 0-100mA - PowerUC

Three-phase current transformer 3TA030BL Rated input 0-150A;0-200A; 0-250A ; 0-300A Rated output 0-100mA

PowerUC

  • €9,28
    Unit price per
Shipping calculated at checkout.

Only 2 left!

pModel:3TA030BL

Characteristics:

full sealed,epoxy encapsulated,high dielectric strength, three phase current combination detection,.

Technical index:

Mounting type:Suspend

Material of the core:Silicon steel sheet

Flame resistance:UL94-V0

Execution standard:GB1208-2006

Operating temperature:-35℃~+85℃

Storage temperature:-45℃~+95℃

Frequency range:50Hz-60Hz

Dielectric strength:3.5KV 50Hz 1min

Electrical parameters:
