DC voltage transducer TDVH Rated input 50V 100V 200V 400V 500V Rated output 0-20mA; 4-20mA; 0-5V; 1-5V; 0-10V
Circular aperture,terminal output,din-rail mounting type;The faulty wiring can lead to product damage,When measuring DC voltage, +HT -HT is not allowed to reverse,The output is linear with primary test current,and the output signal can be directly enter automatic control equipment or PLC port.
Technical index:
Flame resistance: UL94-V0
Operating temperature: -10℃~+70℃
Storage temperature: -25℃~+85℃
Dielectric strength: 2.5KV 50Hz 1min
Overload capacity:8 times 0.1S
Waterproof level: IP00
Electric parameters:
DOWNLOAD
