Busbar built-in type current transformer TA28E Rated input 5A/10A/20A Rated output 100mA/25mA/20mA/10mA/5mA/3.3mA/4mA
Characteristics:
Epoxy resin encapsulated, nanocrystalline core, small outline size, fully enclosed, electrical load remote monitoring, as the input signal of electric control system, lack of phase indicating, electrical energy measuring, motor monitoring.
Technical Index:
Mounting type: PCB
Material of the core: Silicon steel sheet
Flame resistance: UL94-V0
Execution standard: GB20840-2014
Operating temperature: -20°C ~ +70°C
Storage temperature: -30°C ~ +80°C
Frequency range: 50Hz ~ 60Hz
Dielectric strength: 3KV 50Hz 1min
Electrical Parameters:
